DEWMON hygrometers
See the choice of models
| Manufacturer | Partenair |
| Categories | Measure, Measure the humidity, Fixed hygrometers |
| Document to download | |||||
| N190_DewMon_695 | N190_DewMon_695 | Controle des couts energetiques |
Dew point control
Refrigeration and adsorption dryers are the 2 most used technologies in the industry. When a problem occurs, the dew point is no longer reached and the humidity rate thus degraded can have serious economic consequences on the quality of production and / or cause costly breakdowns on pneumatic machines.
As soon as the measured values are no longer in the desired zone, an alarm is triggered allowing rapid intervention before damage occurs.
- Measuring range up to a dew point of -50 ° C
- Plug & Play
- Compressed air supply via a 6 mm quick connector
- Power supply: 100 ... 240 V AC (Option 24 VDC)
- Wall mounting or in the control cabinet
- Accuracy 1 ° C ... 2 ° C
- IP65 enclosure for use in harsh industrial environments
- 4 ... 20 mA output for PLC control or SCADA systems
- Adjustable pre-alarm and main alarm:
- Optical display with flashing red screen
- 2 alarm relays
* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.
Detailed specifications
| Measuring range |
DEWMON 695.300 : -20 °C ... +50 °C DEWMON 695.315 : -50...+20°C |
| Accuracy | 1 °C ... 2 °C dew point |
| Pressure range | -0.1 ... 1.5 MPa |
| Power supply |
100 ... 240 CA/10 VA Option: 24 VDC |
| Measuring mesure | Non-corrosive gases |
| Operating temperature | -10 °C ... +40 °C |
| Storage temperature | -30 °C ... +70 °C |
| Response time t90 | < 30 s (downhill) < 10 s (uphill) |
| Output signal | 4 ... 20 mA 2 relays each 1 W, 230 V CA/3 A |
| Connection | Quick connector hose 6 mm |
| Housing | Aluminium, ABS |
| Protection class | IP 65 |
| Sensor protection | Sintered stainless steel cap, pore size < 30 um |
