PHENIX filters

See the choice of models
+ -
Manufacturer Partenair
Categories Compressed air treatment, Compressed air filters
Particles
Classe iso : 2
9876543210
Residual oil content (20°)
Classe iso : 3
9876543210

Pre-filters - Grade M (1µm)

The PHENIX-M series micron filters can be used as pre-filters on humid air and as protection for the oil separator filters of the PNX-S series.


Their body, made of die-cast aluminium, is protected against corrosion by internal and external cataphoresis treatment.


The filtering elements are provided with a draining outer layer of polyester fibres, ultrasonically welded, offering much greater resistance and efficiency than traditional reticulated foam layers.


Indispensable for all compressed air production plants ! To be installed at the beginning of the line, after the cyclone separator.




  • Particle filtration up to 1μ and residual oil 0.5 mg/m3 at 20°C (respectively ISO 8573 class = 2 and 3)
  • Filter bowl with screw stop. Prevents overtightening, installation and removal without tools.
  • New: Thanks to the QR Code on the filter, you can easily find the manual and certificates for your PHENIX filter!
  • Trap can be dismantled from the outside! Easy removal and maintenance. (From PNX 120 upwards).
  • Maximum efficiency, minimum pressure drop: up to 55% less pressure drop!
  • Longer service life thanks to a specific pleating that increases the filtration surface by 250% compared to a conventional element !
  • Colour coding of the filter elements: red.
  • Total internal and external corrosion protection by KTL Dip-Coating cataphoresis.
  • Filters in compliance with Directive 14/68 for pressure equipment for group 2 gases.
  • Design in accordance with ISO 12500.
  • Manufacturing certified to ISO 9001.
  • Silicone-free materials.

Model

Model Input connection Flowrate (m³/h) My wish
PNX 50 M 3/8“ 50
PNX 60 M 1/2“ 60
PNX 90 M 1/2“ 90
PNX 120 M 3/4“ 120
PNX 220 M 1 “ 220
PNX 370 M 1 “ 370
PNX 540 M 1 ¼“ 540
PNX 700 M 1 ½“ 700
PNX 820 M 2“ 820
PNX 1320 M 2“ 1320
PNX 1500 M 2 ½“ 1500
PNX 2200 M 3“ 2200
Advise me

* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.

(*) Flow rates indicated according to ISO 7183 (20ºC and 1 bar absolute) under 7 bar relative

Particles: > 99.99% at 1μ
Oil: 0.5 mg/m3 at 20°C


The PNX-M pre-filter (1 µm) provides micron pre-filtration or protection for downstream high-efficiency oil removal filters.

Detailed specifications

Detailed specifications PNX-M
Quality class according to ISO 8573-1:2001 Particles: 2
  Residual oil: 3
Particle filtration
Residual oil content at 20°C 0.5mg/m3
Compressed air temperature min/max 1°C / 120°C
Maximum operating pressure Depending on model
Pressure loss (initial) 55 mbars
Pressure loss wet belt 85 mbar
Maximum recommended pressure loss 400 mbar
Element replacement frequency* 8,760 h / 12 months
(*) For normal dusting and correct air quality.

Correction factor depending on operating pressure

Pression Bars 4 5 6 7 8 9 10 11 12 13 14 15 16
Facteur x 0.63 0.75 0.88 1 1.12 1.25 1.37 1.49 1.62 1.74 1.86 1.98 2.10
