BB WSP series compact filtration systems
| Manufacturer | Partenair |
| Categories | Compressed air treatment, Compressed air filters |
|
Particles
|
Classe iso : 1
9876543210
|
|
Residual oil content (20°)
|
Classe iso : 0
9876543210
|
| Document to download | |
| A150_Ensembles_filtres_BBWSP |
For paint booths, varnishes, and other applications requiring high air purity.
BBWSP filtration sets combine 3 stages of filtration into 1 compact unit.
They remove the liquid water, oil and hydrocarbon vapors carried by the compressed air and which are responsible for finishing defects.
They are delivered fully assembled, with pressure regulator and pressure gauge. They have fixing brackets for quick and easy wall installation.
The range consists of 2 sets covering flows up to 60 cubic meters per hour under a pressure of 7 bars.
The sets are delivered complete with their filter elements and 2 automatic drain systems for condensates.
- Particle filtration up to 0.01µ
- (ISO class 8573 = 1)
- Residual oil filtration 0.003 ppm at 20 ° C
- (ISO class 8573 = 1)
- 3 stages of filtration.
- Total corrosion protection by cataphoresis.
- Sealing of the filter elements by double O-ring for increased security.
- Compatible with mineral or synthetic oils.
- 2 automatic traps with manual test.
- Filters in accordance with Directive 2014/68 for pressure equipment for group 2 gases.
- Supplied assembled with wall fixings.
- Design in accordance with ISO 12500.
- ISO 9001 certified manufacturing.
* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.
(1) The activated carbon filter element must be replaced regularly to meet the needs of the application, but at least every 6 months.
For paint booths, varnishes ... and high air purity applications
PBB WSP: A filtration of PRO
The quality of the compressed air is a key factor in ensuring the flawless finish of paints and varnishes.
Water, oil and particles conveyed by compressed air are the source of costly finishing defects that are incompatible with the quality and profitability requirements demanded today.
The BB-WSP assemblies were originally specially developed for the filtration of air intended for paint booths in order to free the user from problems related to poor quality of compressed air.
But they also find their place for all sensitive applications requiring perfect air quality.
Delivered fully assembled, these compact units are very easy to install and their very studied price allows a rapid return on investment.
Detailed specifications
| Quality class according to ISO 8573-1:2001 | Particles : 1 Residual oil : 1 |
| Particle retention | > 99,99% at 0,01µ |
| Residual oil content at 20°C | 0,003 ppm |
| Maximum compressed air temperature | 50°C |
| Recommended compressed air temperature | 25°C max |
| Maximum operating pressure | 16 bars |
| Pressure loss (initial) | 150 mbars |
| Maximum recommended pressure drop | 400 mbars (1) |
Correction factor according to operating pressure
| Pressure | Bars | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
| Factor | x | 0,84 | 0,92 | 1 | 1,07 | 1,13 | 1,19 | 1,25 | 1,31 | 1,41 | 1,46 | 1,51 | 1,51 |
