BIMON MULTI-CHANNEL GRAPHIC DISPLAY / RECORDER
| Manufacturer | Partenair |
| Categories | Measure, Data displays and recorders |
| Document to download | |
| BimonDatamon |
This data display / recorder allows you to measure, display and record all the important parameters (flow, consumption, dew point, pressure, temperature, power consumption, compressor condition, etc.) of a pneumatic installation.
The BIMON 670 / DATAMON 669 offers a powerful and affordable solution for viewing or recording data and screens.
The high resolution 5 "touch screen graphic allows very intuitive operation. Compared to many smaller screens with lower resolution available on the market, the details are easily identifiable here. The versatility of the sensor inputs offers a perfect solution for most measurement tasks.
The BIMON 670 and DATAMON 669 are equipped with a high resolution 5 "color touch screen. This interface allows extremely easy use of the device via the screen. The intelligent PARTENAIR sensors are automatically detected during start-up. some settings, the data logger is operational and displays a practically unlimited memory.
The values measured by four sensors are displayed simultaneously.
A scroll key displays all the sensors (up to 16) and their measured values.
* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.
• High resolution 5 "touch screen
• For all proprietary digital sensors, as well as for sensors from other manufacturers
• Up to 16 sensor inputs
• 2 wall boxes are available: 4 cable grommets or 7 cable grommets
• USB interface for data transfer to a data key or to a PC
• RS-485 (Modbus / RTU, PARTENAIR bus) and Ethernet (Modbus / TCP, PARTENAIR bus)
• 10 W sensor supply (24 V DC)
• Data logger option: 100 million values
• Alarm monitoring with 2 relay outputs
• Integrated web server for remote monitoring
• Various options for system expansion
Detailed specifications
| Box size | 120 x 173 x 67 mm |
| Power supply | A : 100 ... 240 V CA, 15 W |
| B : 18 ... 30 V CC, 15 W | |
| Interface | USB |
| RS-485 | |
| Ethernet | |
| Alarm output | 2 relay, 230 V CA, 3 A |
| Sensor inputs | 2 x SDI inputs or 1 x SDI input et 1 x Modbus input (Modbus input up to 16 sensors) 2 x analog inputs (optional) |
| Data logger | 100 million value (optional) |
| Accuracy | SDI, Modbus : see sensor specifications Analog: 0 ... 20 mA : 0,01 mA 0 ...10 V : 0,01 V Pulse : +/- 1 digit |
| Screen size | 5 inches. |
| Resolution : 800 x 480 | |
| Temp. operating | 0 °C ... +50 °C |
| Temp. storage | -20 °C ... +70 °C |
| Protection index: | IP 65 |
