Motorized valve drain - TEC-44
| Manufacturer | Partenair |
| Categories | Compressed air treatment, Condensate drains for compressed air, Condensate drains by timed solenoid valve |
| Document to download | |
| J135_Purgeur_TEC_44 |
Motorized valve trap for heavily charged condensates
The TEC-44 is a motorized valve trap specially developed for the evacuation of condensates
heavily loaded with solid particles.
The TEC-44 is able to evacuate large volumes of condensate up to an operating pressure of
40 bar.
The valve has a large diameter passage diameter guaranteeing reliable evacuation and no
risk of blockage.
Different evacuation cycles can be memorized and are saved in the event of
power failure by a battery integrated in the control module.
• Operating pressure from 0 to 40 bars.
• 1/2 "BSP connection (NPT optional).
• Indicator for opening the valve.
• LCD screen showing the selected program.
• Time for opening and closing the valve.
• Especially for highly charged compressed air systems.
• Compact design.
• Easy to install.
• CE certified.
• Fully automatic - maintenance free.
• Integrated battery for program backup.
• Anti-blocking system.
* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.
Detailed specifications
| TIMER | |
| Interval time | From 4 minutes to 24 hrs |
| Drainage time | 7,5 secs to 15 Minutes. |
| Available voltages | 115 or 240 VAC - 50/60 Hz |
| Consumption | 4mA max. |
| Operating temp. | 0° C à +60° C |
| Indicators | 1 LED (Valve opening) |
| 1 LED 7 segment ( Selected program) | |
| VALVE | |
| Type | Ball valve, motorized |
| Valve passage diameter | 12 mm |
| Connection | 1/2" BSP or NPT |
| Max. pressure | 40 bar g |
| Valve joint | FPM and Teflon |
| PROGRAMMS | |
| Intervals | Valve cycles |
| 0 4 min | A rotation of 7 secs (non-stop) |
| 1 8 min | B rotation 10 secs, valve open 3 sec. |
| 2 15 min | C rotation 15 secs, valve open 8 sec. |
| 3 30 min | D rotation 20 secs, valve open 13 sec. |
| 4 1 hrs | E rotation 25 secs, valve open 18 sec. |
| 5 2 hrs | F rotation 30 secs, valve open 23 sec. |
| 6 4 hrs | H rotation 45 secs, valve open 38 sec. |
| 7 8 hrs | L 1 minute rotation, valve open 53 sec. |
| 8 16 hrs | P 5 minutes rotation, valve open 4 minutes and 53 sec. |
| 9 24 hrs | O 15 minutes rotation, valve open 14 minutes and 53 sec. |
