VISUAL ALPHANUMERIC DISPLAY
| Manufacturer | Partenair |
| Categories | Measure, Data displays and recorders |
| Document to download | |
| N220_Visu_680 |
VISU 680 is a 2-channel alphanumeric display allowing textual display of the measured data.
It has a digital owner input and an analog input (0 ... 20 mA or 0 ... 10 V)
2 relay outputs allow alarm management independently.
* Select the generic if you don't know which model to choose. The sales department will contact you to determine the appropriate model.
Detailed specifications
| Box | Dimensions : 118 x 11 593 mm |
| Front mounting : 92 x 92 mm | |
| Protection index: IP 65 | |
| Power supply | 100 ... 240 V CA, 50-60 Hz, 15 VA |
| or 18…30 VDC, 15 VA | |
| Interface | USB |
| Alarm output | 2 switching output relays 230 V 3 A |
| Ambient temperature | 0 °C ... +50 °C |
| Sensor input 1 | 1 PARTENAIR sensor with proprietary digital input |
| Sensor input 2 | 1 analog sensor 4…20 mA or 0 ... 10 V |
| Sensor accuracy | see sensor data sheet |
| Accuracy 4…20 mA | 0.01 mA |
| Accuracy 0…10 V | 0.01 V |
| Temp. operating | 0 °C ... +50 °C |
| Temp. storage | -20 °C ... +70 °C |
| Protection | IP65 |
